Mid Drive Motor QS120 2000W 70H 4600RPM with Belt or 428 Sprocket and Fardriver ND72340 V2 Controller(Belt Type)
4.6 (109 items)
Limited Time Sale$1,011.56 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210364976 | Release Date | 2026/04/02 | List Price | $674.38 | Model Number | 210364976 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
controller1 pc x QS120 2KW Mid Drive Motor (Belt or 428 14T Sprocket Type)1 pc x Fardriver Controller ND72340 with BTRated Power: 2000W Rated Voltage: 72VNo-Load Speed: 3200RPM 4600RPM peak with flux weakeningMagnet Height: 70mm 5 pole pairsMax Efficiency: approx 93%Peak Battery Current: 80A (72V)Peak Phase Current: 250A (72V)Working Temperature: 70-130 peak 150 Motor Phase Angel: 60°Waterproof Grade: IP67Cooling: Air coolingPhase wire: 8mm²2). Model Number: ND723403). Max. Bus Current: 120A4). Max. Phase Current: 340A5). Working Voltage: 48V/60V/72V max. 88V6). Compatible Motor Power: 2000W-3000W7). Size: 180mm*118mm*60mm8). Weight: 2KGS
- controller
- High torque output: amplified torque through gear reduction suitable for steep slopes mountains and other complex terrain
- Modularized design: motor controller and sensor are highly integrated and the parts can be replaced separately during maintenance.
- Compatible with a wide range of vehicles: can match vehicles with different wheel diameters and tire types.
- High stability: The motor is located in the middle of the vehicle to improve driving stability especially suitable for high-speed riding or off-road scenarios.
- Wide applicability：It is suitable for DIY electric scooters electric bikes E-Motorcycle Moped etc.
| Model | BUCNYKKHV |
|---|---|
| Brand Name | BUCNYKKHV |
| Model Name | BUCNYKKHV |
| Item Weight | 350 Grams |
| Manufacturer | BUCNYKKHV |
