AHD 720P, Super Clear, 7" Wired Monitor Rear View Backup Camera System for Farm Tractor, Truck, RV, Forklift, Heavy Equipment, EXCAVTORS, Skid Steer

PACKAGE INCLUDING: ◇A. 7" WIRED SINGLE VIEW MONITOR*1 ◇B. AHD 720P WATERPROOF CAMERA*1 ◇C. 15METERS EXTENSION CABLE*1 ◇D. MONITOR POWER CABLE*1 MONITOR SPECIFICATION: ◇7 Inch Wired Color Single View AHD monitor ◇Resolution: 1024(RGB)*600 ◇TV System: NTSC/PAL ◇Multiple menu languages ◇Brightness;450cd/m2 ◇Support 3 cameras video input ◇Separate trigger control wires for AV2/AV3. ◇Menu to set up reversing image delay time 0-15s, mirror/normal image. ◇Monitor will automatic switch-over the image to related camera and back to the original mode when the trigger stops. ◇In standby mode, monitor will turn on automatically when triggered and will switch to back up camera image，Trigger end after shutdown ◇Working voltage: DC12V-36V ◇Keys with LED backlit ◇Built-in short-circuit protector(When installing and connecting the kit, people connects the female 4-pin connectors to the male one from the camera and monitor, they sometimes connect the video pin of the camera to the power pin of the monitor. It may cause a short-cut, the built-in protector may keep the monitor away from being burnt.) CAMERA SPECIFICATIONS: ◇sensor：AHD 720P ◇Video format: PAL / NTSC optional ◇Lens: f=2.5mm ◇Lens Angle: 120° ◇Infrared LED light: 18PCS ◇IR Distance: 35ft ◇Waterproof Rate：IP69K, ◇Housing:aluminum alloy (camera never gets rusty, and has a higher ability in heat radiation than iron housing.) ◇Dustproof, waterproof, hydrochloric acid prevention, explosion prevention

• KEY FEATURES: The 7" monitor delivers crystal-clear and high-definition visuals with 720P resolution. The heavy-duty AHD 720P camera featurs a 120 degree viewing angle, IP69K waterproof rating and night vision for optimal performance in all weather conditions. This kit uses upgraded industrial grade chipset and has 10G vibration resistance ensure reliable performance and durability for heavy-duty vehicle and extreme conditions.
• APPLICATIONS: This is a advanced wired one-camera system which is perfect for large vehicles and heavy equipment, including: Buses, box trucks, garbage trucks, refrigerator trucks bulldozers, excavators, farm tractors, combines, crop sprayers, skid steers, snow plows, forklifts, motor homes, and street sweepers, etc.
• ENHANCED SAFETY & CONVENIENCE: Wide Power Input Range (DC12-36V). Monitor automatically turns on when reversing if trigger wire connected. With two viewing options (view when reversing or remain on continuously). Distance grid lines and mirror/non-mirror image settings can be adjusted via the OSD menu. Built-in surge protection ensures your monitor won't fail due to voltage spikes in heavy machinery electrical systems. Built-in protector prevents damage from reversed power polarities.
• DURABLE & RELIABLE: IP69K waterproof rating and 10G vibration resistance ensure long-lasting performance in harsh conditions and withstand extreme environments. Withstands heavy rain and mud – perfect for outdoor equipment.
• USER-FRIENDLY DESIGN: Buttons with automatic LED backlight for easy operation at night. System remembers previous settings even after being turned off. Supports up to 3 cameras for expanded coverage. Easy Installation: Waterproof aviation 4-pin screw connectors (no BNC/RCA) simplify installation.
• Warranty & Support: 2-Year Warranty: Enjoy peace of mind with our comprehensive warranty. Lifetime Technical Support: Our team is always here to assist you.
